称重传感器安装套件及配件
在这里，您可以找到适用于所有类型称重传感器的 LAUMAS安装套件，以及安装所需的配套配件（底座、接头、约束装置和支脚）。
这些套件的主要功能包括：防倾斜和防侧移约束装置、高度调节、结构支撑面不平行度补偿，以及作为系统和机械结构部件的EN1090认证。
使用搜索筛选功能查找最符合您需求的产品。
for single point load cells AZLI - AZL - AZS - AM
Galvanized steel mounting kit, provided with a self-centring joint foot against lateral forces and anti-tilt.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 300 kg.
Designed for rollers, platforms, tanks, hoppers, etc.
for bending beam load cells FCOL - FCK
Mounting kit made of AISI 304 stainless steel with a compression joint in AISI 304 stainless steel and rubber.
Compensation for any misalignments of the support plates of the structure.
Application range up to 300 kg.
for bending beam load cells FCOL - FCK
Mounting kit made of AISI 304 stainless steel, equipped with upper plate with a compression joint in AISI 304 stainless steel and rubber.
Compensation for any misalignments of the support plates of the structure.
Application range up to 300 kg.
Designed for small tanks, hoppers, platforms, etc.
for bending beam load cells FCOL - FCK
Mounting kits in AISI 304 stainless steel or galvanized steel, provided with a self-centring joint foot against lateral forces and anti-tilt.
Compensation for any misalignments of the support plates of the structure.
Partial height adjustment.
Application range up to 300 kg.
for bending beam load cells FCAX - FCAL
Mounting kit with AISI 304 stainless steel lower plate and alloy aluminum tension ball joint.
Application range up to 500 kg.
for bending beam load cells FCAX - FCAL
Mounting kit made of AISI 304 stainless steel with AISI 304 stainless steel joint + rubber. Compensation for any misalignments of the support plates of the structure.
Application range up to 500 kg.
for bending and shear beam load cells FCAX - FCAL
Mounting kits made of AISI 304 stainless steel provided with upper plate with a compression joint in AISI 304 stainless steel and rubber.
Compensation for any misalignments of the support plates of the structure.
Application range up to 1,500 kg.
for bending and shear beam load cells FCAX - FCAL
Mounting kits made of AISI 304 stainless steel or galvanized steel.
Constraint against lateral forces and anti-tilt by self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Partial height adjustment.
Application range up to 1,500 kg.
for bending and sher beam load cells FCAX - FCAL
AISI 304 stainless steel mounting kits, certified according to EN 1090, which attests its compliance with European quality and safety standards for structural components used in plants and machinery.
Constraint against lateral forces and anti-tilt by self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Partial height adjustment.
Application range up to 1,500 kg.
for bending and shear beam load cells FCAL - FCAX - FTK - FTKL - FTP/-P - FTZ
Mounting kits provided with AISI 304 stainless steel upper plate and compression joint in AISI 304 stainless steel and rubber.
Lower plate and block in galvanized steel.
Compensation for any misalignments of the support plates of the structure.
Up to 2000 kg application range.
Designed for tanks, hoppers, platforms, etc.
for shear and bending beam load cells FTKL - FTP/-P - FTK - FTZ
Mounting kits made of AISI 304 stainless steel or galvanized steel, with compression joint in AISI 304 stainless steel and rubber.
Compensation for any misalignments of the support plates of the structure.
Application range up to 2,000 kg.
Designed for tanks, hoppers, platforms, etc.
for shear and bending beam load cells FTKL - FTP/-P - FTK - FTZ
Mounting kits made of galvanized or stainless steel.
Constraint against lateral forces and anti-tilt by means of a ball joint with nut in galvanized C40 steel or in stainless steel.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 2,000 kg.
Designed for silos, mixing machines, tanks, hoppers subject to vibrations because of parts in motion.
for shear and bending beam load cells FTKL - FTP/-P - FTK - FTZ
Mounting kits made of AISI 304 stainless steel or galvanized steel.
Constraint against lateral forces and anti-tilt by self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 2,000 kg.
Designed for rollers, platforms, tanks, hoppers, etc.
for shear and bending beam load cells FTKL - FTP/-P - FTK - FTZ
Mounting kit made of AISI 304 stainless steel, certified according to EN 1090, which attests its compliance with European quality and safety standards for structural components used in plants and machinery.
Constraint against lateral forces and anti-tilt by self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 2,000 kg.
for shear beam load cells FTP - FTK - FTZ
Mounting kits made of AISI 304 stainless steel or galvanized steel.
Constraint against lateral forces and anti-tilt by self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 5,000 kg.
Designed for rollers, platforms, tanks, hoppers, etc.
for shear beam load cells FTP - FTZ
Mounting kit made of AISI 304 stainless steel, certified according to EN 1090, which attests its compliance with European quality and safety standards for structural components used in plants and machinery.
Constraint against lateral forces and anti-tilt by self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 5,000 kg.
Designed for rollers, platforms, tanks, hoppers, ecc.
for single point, bending beam, shear beam and compression load cells
Plates for self-centring joint foot, for creating constraints against lateral forces and anti-tilt.
Made of AISI 304 and galvanized steel.
Application range up to 5,000 kg.
for shear beam load cells FTP - FTK - FTZ
Mounting kits made of galvanized steel.
Constraint against lateral forces and anti-tilt by a ball joint.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 10,000 kg.
Designed for silos, mixing machines, tanks, hoppers subject to vibrations because of parts in motion.
for compression load cells CLS 1000 - 2000
Mounting kit provided with adjustable upper plate in AISI 304 stainless steel.
Constraint against lateral forces and anti-tilt by stainless steel self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 2,000 kg.
Designed for rollers, platforms, tanks, hoppers, etc.
for compression load cells CLS 1000 - 2000
Mounting kit certified according to EN 1090 which attests its compliance with European quality and safety standards for structural components used in plants and machinery.
Constraint against lateral forces and anti-tilt by a ball joint in AISI 304 stainless steel.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 2,000 kg.
Designed for rollers, platforms, tanks, hoppers, etc
for compression load cell CLS 5000
Mounting kit provided with adjustable upper plate in AISI 304 stainless steel.
Constraint against lateral forces and anti-tilt by stainless steel self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 5,000 kg.
Designed for rollers, platforms, tanks, hoppers, etc.
for compression load cell CLS 5000
Mounting kit certified according to EN 1090, which attests its compliance with European quality and safety standards for structural components used in plants and machinery.
Constraint against lateral forces and anti-tilt by AISI 304 stainless steel self-centring joint foot.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 5,000 kg.
Designed for rollers, platforms, tanks, hoppers, etc.
for compression load cell CLS
Mounting kit with adjustable upper plate in hot galvanized steel.
Constraint against lateral forces and anti-tilt by a ball joint.
Compensation for any misalignments of the support plates of the structure.
Adjustable height.
Application range up to 5,000 kg.
Designed for silos, mixing machines, tanks, hoppers subject to vibrations because of parts in motion.
Plates for mounting accessories for load cells CBL – CBX – CX 15,000
AISI 304 stainless steel plates to construct mounting accessories for compression load cells in combination with specific bases.
Up to 15,000 kg application range.
for compression load cells CBL - CBX - CX
Kit di montaggio realizzati in acciaio inox AISI 304, con lamine contro lo spostamento laterale e vincolo antiribaltamento composto da due barre filettate con dado autobloccante.
Range di applicazione fino a 15.000 kg.
Progettati per la pesatura di sili, serbatoi, miscelatori, tramogge, soggetti a vibrazioni per organi in movimento.
for compression load cells CBL – CBX - CX
Mounting kits made of AISI-304 stainless steel, certified according to EN 1090 which attests its compliance with European quality and safety standards for structural components used in plants and machinery.
Laminas against lateral forces and anti-tilt constraint consisting of two threaded rods with self-locking nut.
Application range up to 15,000 kg.
Designed for silos, tanks, mixing machines, hoppers subject to vibrations because of parts in motion.
for compression load cells CBL - CBX - CX
Mounting kit made of galvanized S355JR construction steel, a cost-effective material which is perfect for use in non-aggressive environments.
AISI 304 stainless steel laminas against lateral forces and anti-tilt constraint consisting of two threaded rods with self-locking nut.
Application range up to 15,000 kg.
Designed for silos, tanks, mixing machines, hoppers subject to vibrations because of parts in motion.
for compression load cells CBL - CBX - CX
Mounting kits made of AISI-304 stainless steel with laminas against lateral forces and anti-tilt constraint consisting of two threaded rods with self-locking nut.
Application range up to 100,000 kg.
Designed for silos, mixing machines, tanks, hoppers subject to vibrations because of parts in motion.
for compression load cells CBL - CBX - CX
Mounting kits made of AISI 304 stainless steel, certified according to EN 1090, which attests its compliance with European quality and safety standards for structural components used in plants and machinery.
Laminas against lateral forces and anti-tilt constraint consisting of two threaded rods with self-locking nut.
Application range up to 100,000 kg.
Designed for silos, mixing machines, tanks, hoppers subject to vibrations because of parts in motion.
for compression load cells CBL - CBX - CX
Mounting kits made of galvanized S355JR construction steel, a cost-effective material which is perfect for use in non-aggressive environments.
AISI 304 stainless steel laminas against lateral forces and anti-tilt constraint consisting of two threaded rods with self-locking nut.
Application range up to 100,000 kg.
Designed for silos, mixing machines, tanks, hoppers subject to vibrations because of parts in motion.
for double shear beam load cell DTX
Mounting kit made of nickel-plated steel alloy for rigid attachment of the load cell. It prevents horizontal movement.
Application range up to 27,000 kg (60 klb).
Designed for on-board weighing, overhead cranes, silos, mixing machines, tanks, hoppers subject to vibrations because of parts in motion or wind effect.
Suitable for high-capacities weighing systems approved for legal use with third parties.
for column load cells COL - COK and double shear beam load cell DTL
Mounting kit made of galvanized steel with two integrated galvanized steel stay rods with a dual ball joint suitable to counter the lateral force.
Anti-tilt constraint consisting of two threaded rods with self-locking nut.
Application range up to 50,000 kg.
Designed for weighing silos, tanks, mixing machines and hoppers subject to vibrations caused by moving parts or wind effect.
STAY RODS FOR MOUNTING ACCESSORIES
Galvanized steel turnbuckle with dual ball-and-socket, to be positioned horizontally.
Equipped with lock for constraint adjustment.
Suitable for static applications.
Galvanized steel plate for anchoring the turnbuckle.
Bolts and pins not included.
Bases for mounting accessories for load cells CBL – CBX - CX
For compression load cells.
Bases for mounting accessories for load cells CBL - CBX - CX
For compression load cells.
for load cells FCAL/X - FCOL - FTK/L - FTP/-P - FTZ - FLC
Self-centring joint feet, made of stainless or galvanized steel, for bending beam, shear beam and compression load cells for foot.
Application range up to 5,000 kg.
for load cells FCAL/X - FCOL - FTK/L - FTP/-P - FTZ - FLC
Ball-mounted self-centring pluggable feet, made of stainless steel.
For shear beam, bending beam and compression for foot load cells.
Application range up to 10,000 kg.
for load cell FLC 3A
Self-centring adjustable hygienic feet, made of stainless steel, for hygienic compression load cells for foot.
Application range up to 20,000 kg.
for tension - compression load cells
for load cells CLS - FTK - FTKL - FTP/-P - FTZ
Axial spherical plain steel bearings to compensate for misalignment of the support plates. For compression, bending beam and shear beam load cells.
Application range up to 10,000 kg.
for load cells FTKL - FTP/-P - FTK - FTZ - CLS
Stainless steel mounting accessory with ball, to compensate for misalignment of the support plates of the structure.
For bending beam, shear beam and compression load cells.
Application range up to 5,000 kg.
for load cells FTKL - FCAL/X - FTP/-P - FTK/Z/L - CLS - FCOL - FCK
Stainless steel & rubber compression joints to compensate for misalignment of the support plates of the structure.
For shear beam, bending beam and compression load cells.
Application range up to 2,000 kg.
